Triple-Ground Track Shoe for Yanmar Medium Excavators (6-Ton Class), Pitch 154mm

Description

Wide range of available as Japanese high quality products

Equipment : Excavator
KMVL P/N :
CENTER TYPE : EX-YAM-TS154/021-450T
LEFT-OS : EX-YAM-TS154/021-450T-OSL
RIGHT-OS : EX-YAM-TS154/021-450T-OSR
Manufacturer : Yanmar
Model :
CENTER TYPE : Vio70
LEFT/RIGHT-OS : Vio70-2.3/B7-3.5
Parts number :
CENTER TYPE : 172187-38160
LEFT-OS : 172455-38130/172455-38130-1
RIGHT-OS : 172455-38140/172455-38140-1
Weight : 6.16 KGS
Remarks :
Length : 450mm
LINK PITCH : 154mm
Thickness : 6mm
MUD hole : YES
Bolt hole : φ14.3
Pad hole : YES
Berco : KM1685/450
USCO :
ITM : Z1506300N0450V
We will propose and provide the best way for the machine. Also, we are possible to provide our products as OEM, ODM and private brand.
If you have any questions, please do not hesitate to contact us!
