FT500 to FT550 Injector Adapter Wiring Kit

Description

• Description
• Downloads

• FT500 to FT550 adapter harness
•  FT500 to FT550 Adapter Harness Manual

Features

FT500 to FT550 plug and play adapter harness is the fastest way of using a FT550 on an existing FT500 installation.
The adapter is 16 inches long and has 2 FT500 connectors (24 and 16 ways), 2 FT550 connectors (2x 26 ways), 2 CAN connectors and 1 connector for strain gauge shifter (4 ways).

Optional (10) FT550 terminals allow you wire additional inputs/outputs that are available on the FT550 compared to the FT500.

Technical Description

• 1 FT500 main connector – 24 ways
• 1 FT500 auxiliary connector – 16 ways
• 1 FT600 A SUPERSEAL connector – 26 ways
• 1 FT600 B SUPERSEAL connector – 26 ways
• 1 CAN-A connector – 4 ways
• 1 CAN-B connector – 2 ways
