Description
FEATURES / SPECS:
- RATED LINE PULL: 7800 LB
- MOTOR: 5.2 HP 12vDC SERIES WOUND
- SWITCH: 450A SEALED CONTACTOR
- CONTROLLER: WIRED: HANDHELD WITH LEAD WIRELESS: OPTIONAL 20156
- BATTERY RECOMMENDATION: 650CCA
- GEAR TRAIN: 3-STAGE PLANETARY
- GEAR RATIO: 218:1
- CLUTCH: FREESPOOLING
- BRAKE: AUTOMATIC LOAD HOLDING IN DRUM
- WARRANTY: 2 YEAR LIMITED
Dimensions:Plate Mounting Bolt Pattern: 12in X 5.8in Winch Mounting Bolt Pattern: 4.5in X 4inWire Rope: 8.1mm (about 0.32 in) X 47.5ft Drum Diameter X L: 2.5in X 2.7in (63.5 X 70mm) Controller Lead Length: 20ft Battery Leads: 6ftWeight: 61 LBS
