Bulldog Winch 7,800 lb Electric Trailer Winch with Steel Cable

Description

FEATURES/SPECS:

• RATED LINE PULL: 7800 LB
• MOTOR: 5.2 HP 12vDC SERIES WOUND
• SWITCH: 450A SEALED CONTACTOR
• CONTROLLER: WIRED: HANDHELD WITH LEAD WIRELESS: OPTIONAL 20156
• BATTERY RECOMMENDATION: 650CCA
• GEAR TRAIN: 3-STAGE PLANETARY
• GEAR RATIO: 218:1
• CLUTCH: FREESPOOLING
• BRAKE: AUTOMATIC LOAD HOLDING IN DRUM
• WARRANTY: 2 YEAR LIMITED

Dimensions:Handheld Controller Length: 20ftBattery Leads: 6ft Drum Diameter X L:  2.5″ X 2.7″ (63.5 X 70mm) Wire Rope: Length: 47.5ft (14.47M) Diameter:5/16in (8.1mm) Winch Mounting Bolt Pattern:  4.5in X 4in Plate Mounting Bolt Pattern: 12in X 5.8in Weight: 61 LBS
