Bulldog Winch 5,800 lb Trailer Winch with 50-Foot Synthetic Rope

Description

FEATURES / SPECS:

• RATED LINE PULL: 5800 LB
• MOTOR: PERMANENT MAGNET 1.87 HP 12vDC
• SWITCH: 450A SEALED CONTACTOR
• CONTROLLER, WIRED: HANDHELD WITH LEAD WIRELESS: OPTIONAL 20156
• BATTERY RECOMMENDATION: 650CCA
• GEAR TRAIN: 3-STAGE PLANETARY
• GEAR RATIO: 218:1
• CLUTCH: FREESPOOLING
• BRAKE: AUTOMATIC LOAD HOLDING IN DRUM
• WARRANTY:  2 YEAR LIMITED

Dimensions:Drum Diameter X L: 2.5in x 2.7in (63.5 X 70mm) Wire Rope: 9/32in X 55ft Winch Mounting Bolt Pattern: 4.5in x 4in Plate Mounting Bolt Pattern: 12in x 5.8in Weight: 57LBS Controller Lead Length: 20ft    Battery Lead Length: 6ft
