1A1 Diamond Grinding Wheel – 100x8x10mm, 8° Taper, 31.75mm Bore, D64 Grit, Sq125 Concentration, Hybrid M405 Bond

Description

• Imperial: 1A1 4″x.315″x.393″ T=.315″ Bore 1.25″ Grit D280 Concentration SQ125 Hybrid Bond M405 (Approx.)
• Metric: 1A1 100x8x10 T=8 Bore 31.75 Grit D64 Concentration SQ125 Hybrid Bond M405
• Most Common Application: Fluting on CNC grinding machine, with good coolant delivery lines. Excellent corner retention, a better option for manufacturing and reconditioning.
• Recommended workpiece: Carbide round tools around 5/16″ OD or larger.
• Working parameters: 12 to 15 m/s = 2,363 to 2,953 ft/min
• Package dimension (mm): 134x56x134
